SN74LS138N

Description:

Encoders, Decoders, Multiplexers & Demultiplexers Line Decoder

Brand:

Quantity:

9500

Quick inquiry:

corporate name

contacts

mobile phone

quantity

询价名称

Details:

Product Category:	Encoders, Decoders, Multiplexers & Demultiplexers
Product:	Decoders / Demultiplexers
Logic Family:	LS
Number of Input Lines:	3 Input
Number of Output Lines:	8 Output
Propagation Delay Time:	41 ns
Supply Voltage - Min:	4.75 V
Supply Voltage - Max:	5.25 V
Minimum Operating Temperature:	0 C
Maximum Operating Temperature:	+ 70 C
Mounting Style:	Through Hole
Package/Case:	DIP-16
Packaging:	Tube
Function:	Decoder/Demultiplexer
Height:	4.57 mm
Length:	19.3 mm
Number of Circuits:	Quad
Operating Temperature Range:	0 C to + 70 C
Series:	SN74LS138
Technology:	Bipolar
Width:	6.35 mm
Brand:	Texas Instruments
Logic Type:	Decoders/Demultiplexers
Supply Current - Max:	6.3 mA
High Level Output Current:	- 0.4 mA
Low Level Output Current:	8 mA
Maximum Clock Frequency:	35 MHz
Operating Supply Voltage:	5 V
Pd - Power Dissipation:	1 mW
Product Type:	Encoders, Decoders, Multiplexers & Demultiplexers
